Ultra-High-Density VSFF Cable

Features:
• 3x Density of Standard LC
• Push-Pull Boot Design
• Optimized Airflow & Ventilation
• Next-Gen 400G/800G Readiness
• Premium Optical Reliability

Download

Description:
Accelerate your next-generation data center infrastructure with our Ultra-High Density VSFF (Very Small Form Factor) Fiber Patch Cable. Explicitly engineered to meet the aggressive requirements of 400G/800G/1.6T data hubs, this cutting-edge cabling solution delivers three times the cabling density of a standard LC duplex connector. Its miniaturized footprint drastically eliminates cable congestion behind ultra-dense patch panels, maximizing rack space and maximizing premium airflow.
Featuring an integrated Push-Pull Boot design, it ensures quick and reliable insertion and extraction without interfering with adjacent ports, even in fully saturated high-density environments. Terminated with premium factory-polished singlemode ferules, this cable provides industry-leading optical performance with exceptional return loss and ultra-low insertion loss for high-speed network continuity.

Specifications：

Item	Specification
Fiber Count	2
Fiber Mode	SM: OS2 \| MM:OM3/OM4
Connector type	MDC/SN/CS
Insertion loss	SM: ≤0.2dB(UPC),≤0.3dB(APC), MM≤0.2dB
Return Loss	SM:≥50dB(UPC),≥65dB(APC)
Wavelength	SM:1310//1550nm \| MM:850/1300nm
Operation Temperature	-40℃ to + 75℃
Storage Temp	-40℃ to + 85℃
Standard Compliant	ROHS, IEC,Telcordia GR-326-CORE
