1. Physical & Mechanical Specifications

Rack Height:

1U / 2U / 4U standard 19-inch rack mount.

Fiber Density

Up to 96 fibers (LC) or 144 fibers (MPO/MTP) per 1U

Material:

Heavy-duty cold-rolled steel (CRS)

Surface Finish

Electrostatic powder coating (scratch and corrosion resistant).

Chassis Design

Sliding drawer layout with independent layered trays.

Cable Management:

Integrated rear cable managers and front blanking panels

2. Connectivity & Adapter Specifications

Adapter Types:

 LC Duplex, LC Quad, MPO, MTP, SC

Polish Types:

UPC (Ultra Physical Contact) / APC (Angled Physical Contact).

Fiber Modes:

Single-mode (OS2) and Multi-mode (OM3 / OM4 / OM5).

Modular Structure

Plug-and-play MPO/MTP to LC Cassettes and adapter plates.

3. Optical Performance Specifications

LC Insertion Loss:

low loss (≤ 0.15 dB) / Standard loss (≤ 0.3 dB).

MPO Insertion Loss:

low loss (≤ 0.35 dB) / Standard loss (≤ 0.6 dB).

Return Loss:

SM UPC ≥ 50 dB / SM APC ≥ 60 dB / MM ≥ 20 dB.

Mating Durability:

> 500 matings.

4. Environmental & Compliance Specifications

Operating Temperature:

-20°C to +60°C (-4°F to +140°F)

Storage Temperature:

 -40°C to +70°C (-40°F to +158°F).

Relative Humidity:

≤ 85% (at +30°C).

Standards Compliance:

TIA/EIA-568.3-D, IEC 61754, RoHS, CE, UL94-V0 (flammability).
